Bushmaster M17s OEM Replacement Parts

As parts become available I will update the list

Part Number and description

Quantity/Availability

PayPal Purchase

Install Video

30-103 - 1/4 High Collar Lock Washer



30-104 -Thrust Washer



30-105 - Barrel Extension Retaining Screw





30-106 - Gas Housing
Not available

30-107 (9349054btp) - Taper Pin (2 per gun)


30-108 - Piston
Not available

30-109 - Gas Cylinder
Not available

30-110 - Link Rod
Not available

30-111 - Operating Rod
Not available

30-112 - Operating Rod Spring
Not available

30-113 - Sleeve Piston
Not available

30-114 - Hand guard Cap
E-mail for availability

30-115 - Lock Nut (2 per gun)
E-mail for availability

30-115W - Lock Nut Wrench

30-116 (8448577) - Lock Washer


30-118 - Sight Base Screw


30-201 - Upper Receiver - Stripped
Not available

30-202-L - Barrel Extension Tube
Different lengths from factory $15

30-204 - Sight Base
Used OEM $25

30-205 - Sight Base/Cocking Handle Screw


30-206 - Spring Washer


30-207 - Sight Base Screw


30-208 - Spring Retainer


30-209 - Cocking Handle
Used OEM $10

30-210 - Cocking Plate
Not available

30-211 - Trigger Spring


30-212 (8448583) - Safety Detent Spring


30-213 - Safety Detent


30-215 - Trigger
K&M Version

30-216 - Trigger Roll Pin


30-217 - Safety


30-218 - Trigger Cam
K&M Version (Lightning)

30-219 - Trigger Cam Roll Pin


30-219 - Trigger and lightning

30-221 - Trigger Bar


30-222 - Cover Plate


30-224 - Cocking Spring


30-230 - Scope Mount
Used OEM $15

30-231 - Rail


30-232 - Rail Retaining Screw


30-301 - Breech Bolt


30-302 (MS16562-98) - Ejector Roll Pin


30-303 (8448512 - Extractor Cartridge


30-304 (8448513) - Extractor Pin


30-305 (8448755sp) - Extractor Spring


30-306C - Firing Pin (Chromoly Steel)
1pc $35
30-306T - Firing Pin (Titanium)
1pc $65
30-307 - Firing Pin Spring (deleted 1998)


30-308 - Cam Pin


30-309 - Bolt Carrier


30-310 (8448515) - Ejector Cartridge


30-311 - Firing Pin Retaining Pin


30-312 (8448516) - Ejector Detent Spring


30-313 - Action Plate


30-314 - Action Rod


30-315 - Action Spring


30-316 - Retainer - Action Rod
3pk $10
30-317 - Bolt Carrier Cap Screw


30-318 - Buffer
1pc $5
30-321 (8448754) - Extractor Spring Insert


30-400 - Hinge Pin


30-408 (MS19060-4808) - A-2 Ball Bearing


30-409 - Hinge Pin Spring


30-400a - Hinge Pin Assembly (400+408+409)


30-410 (8448585) - Tkdwn Pin Detent


30-411 (8448586) - Tkdwn Pin Det. Spring


30-413 - Hammer


30-414 - Hammer Spring


30-415 - Pivot Pin


30-417 - Sear


30-418 - Disconnector


30-419 - Disconnector Spring


30-420 - Ignition Pocket


30-430 (8448571) - Sling Swivel


30-434 - Rear Sling Swivel Roll Pin


30-440 - Ignition Pocket Retaining Clip


30-441 - Bolt Catch


30-442 - Ambi. Magazine Release


30-443 (8448633) - Bolt Catch Spring


30-444 (8448634) - Bolt Catch Plunger


30-445 (MS16562-119) - Spring Pin


30-447 (8448638) - Magazine catch


30-447 (8448638) - Magazine catch


30-449 (8448637) - Magazine Catch Spring


30-451 - Take down Pin


30-452 - Front Sling Swivel Rivet


30-962 - Operator's Manual


Major Assemblies:


30-905 - Barrel /Gas Housing Sub-Assembly


30-925 - Stripped Lwr. Rec./Pistol Grip Asmbly.


*30-965 - Field Repair Kit
